No more line marking. No more wasted time. Just accurate, consistent, and high-speed data acquisition—every time.
01
evoARC easily attaches to third-party scanning systems, enabling you to maximize your current scanner assets. There’s no need for new equipment—simply attach evoARC to your existing setup and unlock advanced capabilities for more accurate and consistent results.
02
With evoARC, you’ll achieve pinpoint accuracy every time. The system’s visual LED indicators provide immediate feedback on key scan positions (12, 3, 6, and 9 o’clock), ensuring precise alignment and eliminating margin for error. This high-precision capability results in higher quality inspections and reduced rework.
03
evoARC’s advanced sensor and control system enables automation of the scanning process, improving workflow efficiency and reducing costs. This automation allows your team to scale inspections quickly, while ensuring data consistency and quality across inspections.
Transform the way you inspect—seamless integration, zero maintenance, total precision.
Capture precise axial data without touching the surface—no wheels, no drag, no cleanup.
Achieve measurement accuracy down to 0.013mm (0.0005″) for consistently reliable results.
Quickly locate 12, 3, 6, and 9 o’clock with visual feedback—no guesswork, no misalignment.
Can be used with single probe mounts like A10 and A31 models for circumferentially encoded weld inspection.
Built to MIL-STD-810G standards, attach and remove evoARC in seconds with an intuitive, screw-less setup.
evoARC supports all PAUT acquisition systems using Lemo 1K.316 and Quadrature Encoding—making it easy to drop into your existing workflow without extra adapters or upgrades.
The evoARC is supplied with everything you need to get to work: A Flexoform mount,16.4′ (5m) cable, Splitter & cable. All supplied in a Nanuk 915 hard case.
evoARC is designed to integrate seamlessly with third-party scanners, including systems like the Olympus FlexoForm. It supports any PAUT acquisition system using Lemo 1K.316 and Quadrature Encoding—so you can upgrade your existing tools without investing in new hardware.
evoARC significantly reduces setup time, improves scan accuracy, and eliminates common causes of rework. Users have reported up to 4x faster inspection coverage, especially in complex environments like offshore rope access or large-diameter piping.
Yes. evoARC is built to MIL-STD-810G standards, meaning it’s engineered for rugged use in extreme conditions. Electronics are encased in resin and it’s been tested to IP67. It’s a non-contact encoder, so there should be minimal wear and tear, and no maintenance is required.
Yes! evoARC features a completely toolless, screwless mounting system for fast, easy installation in the field—no fiddling with tools or fasteners required.
